THERMAL FEATURES

Temperature Control	mK2000 with programmable precision switching PID method
Thermal Block	Silver
Minimum Temperature	-190°C (with optional liquid N₂ cooling)
Maximum Temperature	300°C
Temperature Sensor	100 Ω Platinum RTD
Maximum Heating Rate	+110°C per minute at 100°C
Maximum Cooling Rate	-80°C per minute at 100°C
Minimum Heating and Cooling Rate	±0.01°C per minute
Temperature Resolution	0.01°C
Temperature Stability	±0.05°C (>25°C), ±0.1°C (<25°C)
Power supply	Universal power input - 120 watts Max
Software	Windows 10/11 software to record and export temperature-time data

OPTICAL FEATURES

Optical access	Reflection and transmission capability
Optical windows	Removable and exchangeable windows permit full-spectrum transparency
Minimum Objective Working Distance	7.5 mm
Minimum Condenser Working Distance	17.5 mm
Top Window Aperture	Ø27 mm aperture, Ø31.75mm glass
Top Viewing Angle	±57° from normal
Transmission Aperture	2x3 mm Slottted Transmisison aperture
Bottom Window Aperture	Ø15 mm aperture, Ø18mm glass
Bottom Viewing Angle	±11° from normal
Window Defrost	Integrated top-window defrost port

Sample Heating Area	26 mm x 16 mm
Maximum Sample Width x Length	8 mm x 80 mm
Minimum Sample Length	30 mm
Maximum Sample Thickness	2 mm
Sample Displacment Range	0 mm - 60 mm
Maximum Force	200 N
Force Resolution	±0.1 N (200 N sensor), ±0.01 N (20 N sensor)
Chamber Height	2.2 mm
Maximum Speed	1000 μm/s
Minimum Speed	1.6 μm/s
Atmosphere Control	Supports positive pressure gas purge up to 0.5 Bar to control humidity, condensation, and oxidation Supports rough vacuum down to 1mBar
Frame Cooling	Integrated frame cooling with optional recirculating water chiller system
Mounting	Base model includes tapped holes on frame and removable side-mounted L-Brackets. Horizontal mounting adaptors available for select instruments, or by custom design
Frame Dimensions	264 mm x 148 mm x 29 mm
Weight	3000 g
